M306N0FGTFP Datasheet - Tyco Electronics

M306N0FGTFP 60 W / 225 to 400 MHz CONTROLLED Q BROADBAND RF POWER TRANSISTOR NPN SILICON

SEMICONDUCTOR TECHNICAL DATA Order this document by 2N6439/D The RF Line NPN Silicon RF Power Transistor . . . designed primarily for wideband large signal output amplifier stages in the 225 to 400 MHz frequency range. Guaranteed Performance in 225 to 400 MHz Broadband Amplifier @ 28 Vdc Output Power = 60 Watts over 225 to 400 MHz Band Minimum Gain = 7.8 dB @ 400 MHz Built In Matching Network for Broadband Operation Using Double Match Technique 10.

M306N0FGTFP Datasheet (137.69 KB)

Preview of M306N0FGTFP PDF

Datasheet Details

Part number:

M306N0FGTFP

Manufacturer:

Tyco Electronics

File Size:

137.69 KB

Description:

60 w / 225 to 400 mhz controlled q broadband rf power transistor npn silicon.
