MOC3052, MOC3051 Random-phase triac-driven optocoupler

Description

1..
The UMW MOC305x series devices are optocouplers composed of a GaAs infrared light emitting diode and a singlecrystal silicon chip random phase photoel.

📥 Download Datasheet

MOC3052 Datasheet Preview — This datasheet PDF includes multiple part numbers: MOC3052, MOC3051. Please refer to the document for exact specifications by model.

Datasheet Specifications

Part number: MOC3052, MOC3051
Manufacturer: UMW
File Size: 207.79 KB
Datasheet: MOC3051-UMW.pdf
Description: Random-phase triac-driven optocoupler
Note: This datasheet PDF includes multiple part numbers: MOC3052, MOC3051.
Please refer to the document for exact specifications by model.

Features

* Peak breakdown voltage 600V High isolation voltage between input and output(VISO=5000 Vrms) Compact DIP (Dual In-line Package) housing Lead-free, RoHS compliant UL approved: UL1577, file No. E547318 Microprocessor 115-240VAC peripheral interface Temperature control Motor control Anode 1 Cathode 2 No
