A2V56S40BTP, A2V56S40DTP-7PP - 256Mb SDRAM

A2V56S40BTP Datasheet Preview — This datasheet PDF includes multiple part numbers: A2V56S40BTP, A2V56S40DTP-7PP. Please refer to the document for exact specifications by model.

Datasheet Details

Part number	A2V56S40BTP, A2V56S40DTP-7PP
Manufacturer	UST
File Size	1.02 MB
Description	256Mb SDRAM
Datasheet	A2V56S40DTP-7PP_UST.pdf
Note	This datasheet PDF includes multiple part numbers: A2V56S40BTP, A2V56S40DTP-7PP. Please refer to the document for exact specifications by model.

A2V56S40BTP Product details

Description

(4-BANK x 16,777,216-WORD x 4-BIT) (4-BANK x 8,388,6084-WORD x 8-BIT) (4-BANK x 4,194,304-WORD x 16-BIT) A2V56S20BTP is organized as 4-bank x 16,777,216-word x 4-bit Synchronous DRAM with LVTTL interface and A2V56S30BTP is organized as 4-bank x 8,388,608-word x 8-bit and A2V56S40BTP is organized as 4-bank x 4,194, 304-word x 16-bit.All inputs and outputs are referenced to the rising edge of CLK.A2V56S20BTP,A2V56S30BTP and A2V56S40BTP achieve very high speed clock rates up to 166MHz, and are

Features

ITEM tCLK tRAS tRCD tAC tRC Icc1 Clock Cycle Time (Min. ) CL=2 CL=3 -6 6 42 CL=2 CL=3 V56S20 15 5 60 100 110 130 3 A2V56S20/30/40BTP -7E -7 -75 -8 7 7 45 20 5.4 5.4 63 100 110 130 3 7 45 20 5.4 63 100 110 130 3 10 7.5 45 20 6 5.4 67.5 100 110 130 3 10 8 48 20 6 6 70 95 100 120 3 Unit ns ns ns ns ns ns ns mA mA mA mA Active to Precharge Command Period (Min. ) (Min. ) Row to Column Delay Access Time from CLK Ref /Active Command Period Operation Current (Single Bank) (Max. ) (Min. ) (Max. ) V56S30 V.
