L6219

DUAL FULL-BRIDGE PWM MOTOR DRIVER

Image Manufacturer B2B MPN Description Distributor Stock Quantity Price Buy Now
part STMicroelectronics E-L6219R IC MTR DRV BIPLR 4.75-5.25V 24SO DigiKey 532 5024 units
$1.39

L6219 Datasheet (326.47 KB)

Preview of L6219 PDF

Datasheet Details

Part number:

L6219

Manufacturer:

UTC

File Size:

326.47 KB

Description:

Dual full-bridge pwm motor driver.

L6219 Features

* Interchangeable with SGS L6219

* 750mA Continuous Output Current

* 45V Output Sustaining Voltage

* Internal Clamp Diodes

* Internal PWM Current Control

* low Output Saturation Voltage

* Internal Thermal Shutdown Circuitry

* ORDERING INFORMATION Ordering Number Lead Fre

L6219 General Description

The L6219 motor driver is designed to drive both windings of a bipolar stepper motor or bidirectionally control two dc motors. Both bridges are capable of sustaining 45V and include internal pulse-width modulation (PWM) control of the output current to 750mA .The outputs have been optimized for a l.
