CXA-1191 - FM/AM Radio

Datasheet Summary

Description

The UTC CXA1191 is a one-chip FM/AM radio IC designed for radio-cassette tape recorders and headphone tape recorders.

Features

Small number of peripheral components.
Low current consumption (Vcc=3V) FM: lD=5.3mA (Typ. ) AM: lD=3.4mA (Typ. ).
Built-in FM/AM select switch.
Large current of AF amplifier DIP-28.
