UC1526 Datasheet, Modulator, Unitrode

UC1526 Features

• Modulator
• 8 To 35V Operation
• 5V Reference Trimmed To ±1%
• 1Hz To 400kHz Oscillator Range
• Dual 100mA Source/Sink Outputs
• Digital Current Limiting <

PDF File Details

Part number:

UC1526

Manufacturer:

Unitrode

File Size:

608.43kb

Download:

📄 Datasheet

Description:

Regulating pulse width modulator. The UC1526 is a high performance monolithic pulse width modulator circuit designed for fixed-frequency switching regulators and other

UC1526 Application

• Applications Included in an 18-pin dual-in-line package are a temperature compensated voltage reference, sawtooth oscillator, error amplifier, puls
