Part number:
VBL1603
Manufacturer:
VBsemi
File Size:
708.41 KB
Description:
N-channel mosfet
VBL1603
VBsemi
708.41 KB
N-channel mosfet
* Halogen-free According to IEC 61249-2-21 Definition
* TrenchFET® Power MOSFET
* Package with Low Thermal Resistance
* 100 % Rg and UIS Tested
* Compliant to RoHS Directive 2002/95/EC D2PAK (TO-263) GD S D G S N-Channel MOSFET ABSOLUTE MAXIMUM RATINGS (TC
