VS3060AS - 30V/20A N-Channel Advanced Power MOSFET

Datasheet Summary

Description

VS3060AS designed by the trench processing techniques to achieve extremely low on-resistance.

Features

  • Low On-Resistance.
  • Fast Switching.
  • Repetitive Avalanche Allowed up to Tjmax.
  • Lead-Free, RoHS Compliant.
  • Green Product.
