ACAS0612AT, ACAS0606AT Datasheet - Vishay Siliconix

ACAS0612AT - Precision Thin Film Chip Resistor Array

ACAS 0606 AT ACAS 0612 AT EIA size 0606 0612 Metric size RR1616M RR1632M Configuration, isolated 2 x 0603 4 x 0603 Design: All equal values (AE) AE AE Two pairs of values (TP) TP Different values (DF) Resistance values DF 47  to 150 k (1) Absolute tolerance ± 0.1 % Relative t.

www.vishay.com ACAS 0606 AT, ACAS 0612 AT - Precision Vishay Beyschlag Precision Thin Film Chip Resistor Array Superior Moisture Resistivity ACAS 0606 AT and ACAS 0612 AT precision automotive grade thin film chip resistor arrays with convex terminations combine the proven reliability of discrete chip resistors with the advantages of chip resistor arrays. Defined relative tolerance (matching) and relative TCR (tracking) make this product perfectly suited for applications with outstanding requi.

ACAS0612AT Features

* Superior moisture resistivity, |R/R| < 0.5 % (85 °C; 85 % RH; 1000 h)

* Rated dissipation P70 up to 125 mW per resistor

* ESD stability 1000 V, human body model

* Relative TCR down to ± 5 ppm/K (tracking)

* Relative tolerance down to ± 0.05 % (matching)
