DF1506S Datasheet, Rectifiers, Vishay Siliconix

DF1506S Features

• Rectifiers
• UL recognition, file number E54214
• Ideal for automated placement
• High surge current capability
• Meets MSL level 1, per J-STD-020, LF maximum peak

PDF File Details

Part number:

DF1506S

Manufacturer:

Vishay ↗ Siliconix

File Size:

80.96kb

Download:

📄 Datasheet

Description:

(df15005s - df1510s) miniature glass passivated single-phase surface mount bridge rectifiers.

DF1506S Application

• Applications General purpose use in AC/DC bridge full wave rectification for SMPS, lighting ballaster, adapter, battery charger, home appliances, of
