SUM50N06-16L Datasheet, Level, Vishay Siliconix

SUM50N06-16L Features

• Level PRODUCT SUMMARY V(BR)DSS (V) 60 rDS(on) (W) 0.016 @ VGS = 10 V 0.022 @ VGS = 4.5 V ID (A) 50 43 D TrenchFETr Power MOSFET D 175_C Junction Temperature APPLICATIONS D 12-V Automotive

PDF File Details

Part number:

SUM50N06-16L

Manufacturer:

Vishay ↗ Siliconix

File Size:

70.18kb

Download:

📄 Datasheet

Description:

N-channel 60-v (d-s) 175c mosfet / logic level.

SUM50N06-16L Application

• Applications D 12-V Automotive Systems
• Load Switch
• Motor Drive
• DC/DC D TO-263 DRAIN connected to TAB G D S Top View

TAGS

SUM50N06-16L

Vishay Siliconix
