FGP50D Datasheet, Rectifier, Vishay

FGP50D Features

• Rectifier
• Superectifier structure for high reliability condition
• Cavity-free glass-passivated junction
• Ultrafast reverse recovery time
• Low forward voltage

PDF File Details

Part number:

FGP50D

Manufacturer:

Vishay ↗

File Size:

70.06kb

Download:

📄 Datasheet

Description:

Glass passivated ultrafast plastic rectifier.

FGP50D Application

• Applications For use in high frequency rectification and freewheeling application in switching mode converters and inverters for consumer, computer,
