SMF22A

Surface Mount ESD Protection Diodes

SMF22A Features

* 200 W peak pulse power capability with a 10/1000 μs waveform, repetition rate (duty cycle): 0.01 % Available

* Low profile package

* Wave and reflow solderable

* ESD immunity acc. IEC 61000-4-2 ± 30 kV contact discharge ± 30 kV air discharge

* ESD capa

SMF22A Datasheet (141.05 KB)

Preview of SMF22A PDF

Datasheet Details

Part number:

SMF22A

Manufacturer:

Vishay ↗

File Size:

141.05 KB

Description:

Surface mount esd protection diodes.
www.vishay.com SMF5V0A to SMF58A Vishay Semiconductors Surface-Mount ESD Protection Diodes eSMP® Series 1 2 20278 SMF (DO-219AB) MARKING (examp.
