SMF26A, SMF5V0A Datasheet - Vishay

SMF26A - Surface Mount ESD Protection Diodes

SMF26A Features

* 200 W peak pulse power capability with a 10/1000 μs waveform, repetition rate (duty cycle): 0.01 % Available

* Low profile package

* Wave and reflow solderable

* ESD immunity acc. IEC 61000-4-2 ± 30 kV contact discharge ± 30 kV air discharge

* ESD capa

Datasheet Details

SMF26A, SMF5V0A

141.05 KB

Surface mount esd protection diodes.

This datasheet PDF includes multiple part numbers: SMF26A, SMF5V0A.
Please refer to the document for exact specifications by model.
