VS-E5PX7506LHN3 - 75A Hyperfast Rectifier

Vishay

VS-E5PX7506LHN3 Datasheet Preview — Preview of VS-E5PX7506LHN3 PDF

Datasheet Details

Part number	VS-E5PX7506LHN3
Manufacturer	Vishay ↗
File Size	186.73 KB
Description	75A Hyperfast Rectifier
Datasheet	VS-E5PX7506LHN3-Vishay.pdf

VS-E5PX7506LHN3 Product details

Description

/ APPLICATIONS Featuring a unique combination of low conduction and switching losses, this rectifier is the right choice for soft switched and resonant converters, as well as medium frequency hard switching converters.

Features

Hyperfast and optimized Qrr.
Best in class forward voltage drop and switching losses trade off.
Optimized for high speed operation.
175 °C maximum operating junction temperature.
Polyimide passivation.
AEC-Q101 qualified meets JESD 201 class 2 whisker test.
Material categorization: for definitions of compliance please see www. vishay. com/doc?99912.
