SMZ1200A, SMZ1110A-WON Datasheet - WON-TOP

SMZ1200A 1.0W SURFACE MOUNT ZENER DIODE

SMZ1200A Features

* Low Profile 1.33mm Max. Case Height

* 1.0W Power Dissipation

* 3.3V

* 330V Nominal Zener Voltage

* 5% Standard Vz Tolerance

* Low Inductance C

* For Use in Voltage Regulator or Reference

* Plastic Material

* UL Recognition Flammability Classific

SMZ1110A-WON-TOP.pdf

This datasheet PDF includes multiple part numbers: SMZ1200A, SMZ1110A-WON. Please refer to the document for exact specifications by model.
SMZ1200A Datasheet Preview Page 2 SMZ1200A Datasheet Preview Page 3

Datasheet Details

Part number:

SMZ1200A, SMZ1110A-WON

Manufacturer:

WON-TOP

File Size:

87.46 KB

Description:

1.0w surface mount zener diode.

Note:

This datasheet PDF includes multiple part numbers: SMZ1200A, SMZ1110A-WON.
Please refer to the document for exact specifications by model.
