SMZ1300A, SMZ1110A-WON, 1.0W SURFACE MOUNT ZENER DIODE

® WON-TOP ELECTRONICS .

SMZ1110A-WON-TOP.pdf

SMZ1300A Datasheet Preview — This datasheet PDF includes multiple part numbers: SMZ1300A, SMZ1110A-WON. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

SMZ1300A, SMZ1110A-WON

Manufacturer:

WON-TOP

File Size:

87.46 KB

Description:

1.0W SURFACE MOUNT ZENER DIODE

Note:

This datasheet PDF includes multiple part numbers: SMZ1300A, SMZ1110A-WON.
Please refer to the document for exact specifications by model.

Features

* Low Profile 1.33mm Max. Case Height
* 1.0W Power Dissipation
* 3.3V
* 330V Nominal Zener Voltage
* 5% Standard Vz Tolerance
* Low Inductance C
* For Use in Voltage Regulator or Reference
* Plastic Material
* UL Recognition Flammability Classific
