XP3N5R0AYT N-CHANNEL ENHANCEMENT MODE POWER MOSFET

YAGEO

Description

XP3N5R0AYT Halogen-Free Product N-CHANNEL ENHANCEMENT MODE POWER MOSFET ▼ Simple Drive Requirement D ▼ Small Size & Ultra_Low RDS(ON) ▼ RoHS Compl.
XP3N5R0A series are innovated design and silicon process technology to achieve the lowest possible on-resistance and fast switching performance.

📥 Download Datasheet

XP3N5R0AYT Datasheet Preview — Preview of XP3N5R0AYT PDF

Datasheet Specifications

Part number: XP3N5R0AYT
Manufacturer: YAGEO
File Size: 424.06 KB
Datasheet: XP3N5R0AYT-YAGEO.pdf
Description: N-CHANNEL ENHANCEMENT MODE POWER MOSFET

Applications

* The PMPAK ® 3 x 3 package is special for voltage conversion application using standard infrared reflow technique with the backside heat sink to achieve the good thermal performance. BVDSS RDS(ON) 30V 5mΩ D D D D S S S G PMPAK® 3 x 3 Absolute Symbol Maximum RatingPsa@ramTejt=er25o. C(unless

XP3N5R0AYT Distributors

📁 Related Datasheet

XP301-149 XP3112 XP3182 XP3201 XP3462 XP3473

📌 All Tags

XP3N5R0AYT N-CHANNEL ENHANCEMENT MODE POWER MOSFET YAGEO

YAGEO XP3N5R0AYT-like datasheet
