Part number:
UG2JA
Manufacturer:
Yangzhou Yangjie
File Size:
224.35 KB
Description:
Surface mount ultra fast recovery rectifier.
Datasheet Details
UG2JA Features
* Low profile package
* Ideal for automated placement
* Glass passivated chip junction
* High forward surge capability
* Super Fast reverse recovery time
* Meets MSL level 1, per J-STD-020, LF maximum peak of 260 °C Typical Applications For use in high frequency rectification
Datasheet Details
UG2JA
Yangzhou Yangjie
224.35 KB
Surface mount ultra fast recovery rectifier.
