BUF05703, BUF07703 - Multi-Channel LCD Gamma Correction Buffer

BUF05703 Description

www.ti.com BUF07703 BUF06703 BUF05703 SBOS269C * MARCH 2003 * REVISED APRIL 2010 Multi-Channel LCD Gamma Correction Buffer Check for .
The BUFxx703 are a series of multi-channel buffers targeted towards gamma correction in high-resolution liquid crystal display (LCD) panels.

BUF05703 Features

* 1
* 23 Gamma Correction Channels: 6, 4
* Integrated VCOM Buffer
* Excellent Output Current Drive:
* Gamma Channels: > 10mA
* VCOM: > 100mA typ
* Large Capacitive Load Drive Capability
* Rail-to-Rail Output
* PowerPAD™ Package: BUF07703

BUF05703 Applications

* LCD Flat Panel Displays

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: BUF05703, BUF07703. Please refer to the document for exact specifications by model.
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
BUF05703, BUF07703
Manufacturer
Texas Instruments ↗
File Size
792.23 KB
Datasheet
BUF07703-etcTI.pdf
Description
Multi-Channel LCD Gamma Correction Buffer
Note
This datasheet PDF includes multiple part numbers: BUF05703, BUF07703.
Please refer to the document for exact specifications by model.
