CD74HC04M Datasheet, Inverter, Texas Instruments

CD74HC04M Features

• Inverter
• Buffered inputs
• Wide operating voltage range: 2 V to 6 V
• Wide operating temperature range:
    –55°C to +125°C
• Supports fanout up to

PDF File Details

Part number:

CD74HC04M

Manufacturer:

Texas Instruments ↗

File Size:

1.16MB

Download:

📄 Datasheet

Description:

Hex inverter. This device contains six independent inverters. Each gate performs the Boolean function Y = A in positive logic. Device Information

CD74HC04M Application

• Applications
• Synchronize inverted clock inputs
• Invert a digital signal 3 Description This device contains six independent inve
