LM1117I

800-mA Low-Dropout Linear Regulator

LM1117I Features

* 1 For a newer drop-in alternative, see the TLV1117

* Available in 1.8 V, 2.5 V, 3.3 V, 5 V, and Adjustable Versions

* Space-saving SOT-223 and WSON packages

* Current limiting and thermal protection

* Output current: 800 mA

* Line regulation: 0.2% (ma

LM1117I General Description

The LM1117 is a low dropout voltage regulator with a dropout of 1.2 V at 800 mA of load current. The LM1117 is available in an adjustable version, which can set the output voltage from 1.25 to 13.8 V with only two external resistors. In addition, it is available in five fixed voltages, 1.8 V, 2.5 V,.

LM1117I Datasheet (2.55 MB)

Preview of LM1117I PDF

Datasheet Details

Part number:

LM1117I

Manufacturer:

Texas Instruments ↗

File Size:

2.55 MB

Description:

800-ma low-dropout linear regulator.
Product Folder Order Now Technical Documents Tools & Software Support & Community Reference Design LM1117 SNOS412O

* FEBRUARY 2000
<.
