LM25101C

Half-Bridge Gate Drivers

LM25101C Features

* 1 Independent High and Low Driver Logic Inputs

* Bootstrap Supply Voltage up to 100-V DC

* Drives Both a High-Side and Low-Side N-Channel MOSFETs

* Fast Propagation Times (25 ns Typical)

* Drives 1000-pF Load With 8-ns Rise and Fall Times

* Excellent

LM25101C General Description

The LM25101 high-voltage gate driver is designed to drive both the high-side and the low-side N-Channel MOSFETs in a synchronous buck or a half-bridge configuration. The A version provides a full 3-A of gate drive while the B and C versions provide 2-A and 1-A, respectively. The outputs are independ.

LM25101C Datasheet (1.92 MB)

Preview of LM25101C PDF

Datasheet Details

Part number:

LM25101C

Manufacturer:

Texas Instruments ↗

File Size:

1.92 MB

Description:

Half-bridge gate drivers.
Product Folder Sample & Buy Technical Documents Tools & Software Support & Community Reference Design LM25101 SNVS859C

* JULY 2012
<.
