LM331 Datasheet, Converters, Texas Instruments

LM331 Features

• Converters
• 1 Ensured Linearity 0.01% Maximum
• Improved Performance in Existing Voltage-to- Frequency Conversion Applications
• Split or Single-Supply Operation

PDF File Details

Part number:

LM331

Manufacturer:

Texas Instruments ↗

File Size:

1.03MB

Download:

📄 Datasheet

Description:

Precision voltage-to-frequency converters. The LMx31 family of voltage-to-frequency converters are ideally suited for use in simple low-cost circuits for analog-to-digital conv

LM331 Application

• Applications
• Split or Single-Supply Operation
• Operates on Single 5-V Supply
• Pulse Output Compatible With All Logic For
