SN54HC164W Datasheet, Registers, Texas Instruments

SN54HC164W Features

• Registers
• 1 Wide Operating Voltage Range of 2 V to 6 V
• Outputs Can Drive Up to 10 LSTTL Loads
• Low Power Consumption, 80-μA Maximum ICC
• Typical tpd = 20 ns <

PDF File Details

Part number:

SN54HC164W

Manufacturer:

Texas Instruments ↗

File Size:

1.28MB

Download:

📄 Datasheet

Description:

8-bit parallel-out serial shift registers. These 8-bit shift registers feature AND-gated serial inputs and an asynchronous clear (CLR) input. The gated serial (A and B) inputs

SN54HC164W Application

• Applications
• Programable Logic Controllers
• Appliances
• Video Display Systems
• Output Expander 3 Description T
