TPS61201 Datasheet, Converter, Texas Instruments

✔ TPS61201 Features

1 More than 90% Efficiency at
300 mA Output Current at 3.3 V (VIN ≥ 2.4 V)
600 mA Output Current at 5 V (VIN ≥ 3 V)
Automatic Transition between Boost Mode and Dow

✔ TPS61201 Application

All Single-Cell, Two-Cell and Three-Cell Alkaline, NiCd or NiMH or Single-Cell Li Battery Powered Products

PDF File Details

Texas Instruments manufacturer logo and representative part image

Part number:

TPS61201

Manufacturer:

Texas Instruments ↗

File Size:

2.55MB

Download:

📄 Datasheet

Description:

Low input voltage synchronous boost converter. The TPS6120x devices provide a power supply solution for products powered by either a single-cell, two-cell, or three-cell alkaline,

📥 Download PDF (2.55MB)
