74HC32D Datasheet, gate equivalent, nexperia

74HC32D Features

• Gate
• Wide supply voltage range from 2.0 to 6.0 V
• CMOS low power dissipation
• High noise immunity
• Latch-up performance exceeds 100 mA per JESD 78 Class

PDF File Details

Part number:

74HC32D

Manufacturer:

nexperia ↗

File Size:

234.78kb

Download:

📄 Datasheet

Description:

Quad 2-input or gate. The 74HC32; 74HCT32 is a quad 2-input OR gate. Inputs include clamp diodes. This enables the use of current limiting resistors to int
