TP1564AL1-S Overview
Key Specifications
Package: SOP
Operating Voltage: 5 V
Max Voltage (typical range): 7 V
Length: 8.65 mm
Description
Supply Voltage: 2.5 V to 6 V - Low Supply Current: Typical 600-μA per Channel - Rail-to-Rail Input and Output - Bandwidth: Typical 6 MHz - Slew Rate: Typical 4.5 V/μs - Excellent EMI Suppress Performance - Offset Voltage: Maximum ±3 mV - Offset Voltage Temperature Drift: Typical 1 μV/°C - Low Noise: Typical 19 nV/√Hz at 1 kHz - High Output Capability: Typical 100 mA - -40°C to 125°C Operation Temperature Range - Qualified for Automotive Applications with AEC-Q100 Reliability Test.
