TP1564AL1 - Op Amps

Download the TP1564AL1 datasheet PDF (TP1561AL1 included). The manufacturer datasheet provides complete specifications, pinout details, electrical characteristics, and typical applications for op amps.

Description

The TP156XAL1 series are CMOS dual, and quad RRIO opamps with low offset, low power and stable high frequency response.

Features

  • Supply Voltage: 2.5V to 6.0V.
  • Low Supply Current: typical 600μA per channel.
  • Rail to Rail Input and Output.
  • Bandwidth: typical 6 MHz.
  • Slew Rate: typical 4.5V/μs.
  • Excellent EMI Suppress Performance.
  • Offset Voltage: maximum ±3mV.
  • Offset Voltage Temperature Drift: typical 1 μV/°C.
  • Low Noise: typical 19 nV/√Hz at 1kHz.
  • High Output Capability: typical 100mA.
  • 40°C to 125°C Operation Temperature Range.
  • Green, Popular Type Package App.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (TP1561AL1-3Peak.pdf) that lists specifications for multiple related part numbers.

Datasheet Details

Part number TP1564AL1
Manufacturer 3Peak
File Size 1.24 MB
Description Op Amps
Datasheet download datasheet TP1564AL1 Datasheet

📁 Similar Datasheet

  • TP150A - Current Transducers (Topstek)
  • TP150S - LCD (Han Touch)
  • TP152C12D4 - 450mA High PSRR Voltage Regulator (TECH PUBLIC)
  • TP152C12D6 - 450mA High PSRR Voltage Regulator (TECH PUBLIC)
  • TP152C12S3L - 450mA High PSRR Voltage Regulator (TECH PUBLIC)
  • TP152C12S5 - 450mA High PSRR Voltage Regulator (TECH PUBLIC)
  • TP152C15D4 - 450mA High PSRR Voltage Regulator (TECH PUBLIC)
  • TP152C15D6 - 450mA High PSRR Voltage Regulator (TECH PUBLIC)
  • TP152C15S3L - 450mA High PSRR Voltage Regulator (TECH PUBLIC)
  • TP152C15S5 - 450mA High PSRR Voltage Regulator (TECH PUBLIC)
Other Datasheets by 3Peak

Full PDF Text Transcription

Click to expand full text
Features ⚫ Supply Voltage: 2.5V to 6.0V ⚫ Low Supply Current: typical 600μA per channel ⚫ Rail to Rail Input and Output ⚫ Bandwidth: typical 6 MHz ⚫ Slew Rate: typical 4.5V/μs ⚫ Excellent EMI Suppress Performance ⚫ Offset Voltage: maximum ±3mV ⚫ Offset Voltage Temperature Drift: typical 1 μV/°C ⚫ Low Noise: typical 19 nV/√Hz at 1kHz ⚫ High Output Capability: typical 100mA ⚫ –40°C to 125°C Operation Temperature Range ⚫ Green, Popular Type Package Applications ⚫ White Goods ⚫ Motor Control TP1561AL1/TP1562AL1/TP1564AL1 6MHz, 600μA, RRIO, Op Amps Description The TP156XAL1 series are CMOS dual, and quad RRIO opamps with low offset, low power and stable high frequency response.
