AZ4012-01F
Features
ESD Protect for 1 Line with Unidirectional. Provide ESD protection for a line to IEC 61000-4-2 (ESD) ±24k V (air), ±18k V (contact) IEC 61000-4-4 (EFT) 60A (5/50ns) Suitable for, 12V and below, operating voltage applications Ultra Small package saves board space Protect one I/O line or one power line Fast turn-on and Low clamping voltage Solid-state silicon-avalanche and active circuit triggering technology Green part
AZ4012-01F is a unique design which includes proprietary clamping cell in a single package. During transient conditions, the proprietary clamping cell prevents over-voltage on the power line or control/data lines, protecting any downstream ponents. AZ4012-01F may be used to meet the ESD immunity requirements of IEC 61000-4-2, Level 4 (±15k V air, ±8k V contact discharge).
Circuit Diagram / Pin Configuration
Applications
Cellular Handsets and Accessories Small Panel Modules PDA’s Portable Devices Digital Cameras Touch Panels Notebooks and Handhelds MP3 Players...
