HSSR-7112 Overview
The Broad® HSSR-7110, HSSR-7111, HSSR-7112, HSSR-711E, and SMD 5962-9314001, 5962-93140021 are single-channel power MOSFET optocouplers, constructed in eight-pin, hermetic, dual-in-line, ceramic packages. The devices operate exactly like a solid-state relay. The products are capable of operation and storage over the full military temperature range and can be purchased as a mercial product (HSSR-7110), with full...
HSSR-7112 Key Features
- Dual marked with device part number and DLA standard microcircuit drawing (SMD)
- ac/dc signal and power switching
- pact solid-state bidirectional switch
- Manufactured and tested on a MIL-PRF-38534 certified
- QML-38534, Class H and Class E
- Hermetically sealed 8-pin, dual-in-line package
- Small size and weight
- Performance guaranteed over -55°C to +125°C
- Connection A 0.8A, 1.0Ω
- Connection B 1.6A, 0.25Ω
