Diodes Incorporated MMST5551
160V NPN SMALL-SIGNAL TRANSISTOR
| Part No. | MMST5551 |
|---|---|
| Datasheet | MMST5551 Download |
| Manufacturer |  Diodes Incorporated |
| Description | 160V NPN SMALL-SIGNAL TRANSISTOR |
| Buy | Stock & Price |
FEATURES
● Epitaxial Planar Die Construction● Ultra-Small Surface-Mount Package
● Complementary PNP Type: MMST5401
● Ideal for Low Power Amplification and Switching
● Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
● Halogen and Antimony Free. “Green” Device (Note 3)
● For automotive applications requiring specific change control (i.e.: parts qualified to AEC-Q100/101/104/200, PPAP capable, and manufactured in IATF 16949 certified facilities), please refer to the related automotive grade (Q-suffix) part. A listing can be found at
● This part is qualified to JEDEC standards (as references in AEC-Q) for High Reliability.
MECHANICAL DATA
● Package: SOT323● Package Material: Molded Plastic. “Green” Molding Compound. UL Flammability Rating 94V-0
● Moisture Sensitivity: Level 1 per J-STD-020
● Terminals: Finish - Matte Tin Plated Leads, Solderable per MIL-STD-202, Method 208
● Weight: 0.006 grams (Approximate) SOT323 C B Top View E Device Symbol Top View Pinout Ordering Information (Note 4) Orderable Part Number MMST5551-7-F Package SOT323 Marking K4N Reel Size (inches) 7 Tape Width (mm) 8 Packing Qty.
