EMP8041 - Low-Dropout Linear Regulator

General Description

The EMP8041 is a high voltage, low quiescent current, low dropout regulator with 100mA output driving capacity.

Key Features

  • also include bandgap voltage reference, constant current limiting and thermal overload protection. Both miniature SOT-23-5 and SOT-89-3 package options are offered to provide flexibility for different.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
EMP8165 2A Ultra Low Dropout Voltage Regulator ESMT
EMP8165A 2A Ultra Low Dropout Voltage Regulator ESMT
EMP85N10CS Single N-Channel Logic Level Enhancement Mode Field Effect Transistor Excelliance MOS
EMP85N10H Single N-Channel Logic Level Enhancement Mode Field Effect Transistor Excelliance MOS
EMP-8603 Mini-PCI Adapter EnGenius

Other Datasheets by ESMT (Elite Semiconductor Microelectronics Technology)

Part Number Description
EMP8040 Low-Dropout Linear Regulator
EMP8042 Low-Dropout Linear Regulator
EMP8046 50mA Ultra-Low Quiescent Current LDO Linear Regulator
EMP8020 300mA CMOS Linear Regulator
EMP8021 600mA CMOS Linear Regulator

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
ESMT/EMP EMP8041 High Input Voltage, Low Quiescent Current, Low-Dropout Linear Regulator General Description The EMP8041 is a high voltage, low quiescent current, low dropout regulator with 100mA output driving capacity. The EMP8041, which operates over an input range of 3V to 36V, is stable with any capacitors, whose capacitance is larger than 1μF, and suitable for powering battery-management ICs because of the virtue of its low quiescent current consumption and low dropout voltage. Below the maximum power dissipation (please refer to Note. 5), It guarantees delivery of 100mA output current, and supports preset output voltages ranging from 1.3V to 6.0V with 0.1V increment.
