Galaxy Century Microelectronics 2SD1766
NPN Silicon Epitaxial Planar Transistor
| Part No. | 2SD1766 |
|---|---|
| Datasheet | 2SD1766 Download |
| Manufacturer | Galaxy Century Microelectronics |
| Description | NPN Silicon Epitaxial Planar Transistor |
| Buy | Stock & Price |
FEATURES
● Low saturation voltage● High saturation current capability
● Complementary pair with 2SB1188
● RoHS compliant with Halogen-free NPN Silicon Epitaxial Planar Transistor 2SD1766
MECHANICAL DATA
● Case: SOT-89● Molding compound: UL flammability classification rating 94V-0
● Terminals: Tin-plated; solderability per MIL-STD-202, Method 208 SOT-89 Ordering Information Part Number 2SD1766 Package SOT-89 Shipping Quantity 1000 pcs / Tape & Reel Marking Code DBP/DBQ/DBR
MAXIMUM RATINGS
(@ TA = 25°C unless otherwise specified) Parameter Collector-Base Voltage Collector-Emitter Breakdown Voltage Emitter-Base Breakdown Voltage Collector Current (Continuous) Collector Current (Peak) Symbol VCBO VCEO VEBO IC ICM Value 40 32 5 2 2 Unit V V V A A Thermal Characteristics Parameter Symbol Power Dissipation (TA = 25°C) PD Thermal Resistance Junction-to-Air *1 RθJA Thermal Resistance Junction-to-Case *1 RθJC Thermal Resistance Junction-to-Lead *1 RθJL Junction Temperature TJ Storage Temperatu...
