BAV74 - Dual surface mount switching diode

Key Features

  • z For high-speed switching appilication. z Common cathode. Pb Lead-free.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
BAV74 SURFACE MOUNT FAST SWITCHING DIODE LITE-ON
BAV74 SWITCHING DIODE BLUE ROCKET ELECTRONICS
BAV74 High-speed double diode NXP
BAV74 Silicon Switching Diode Array (For high-speed switching Common cathode) Siemens Semiconductor Group
BAV74 Small Signal Diode Fairchild Semiconductor

Other Datasheets by Galaxy Microelectronics

Part Number Description
BAV70 Dual surface mount switching diode
BAV70DW Surface Mount Fast Switching Diodes
BAV70M Dual surface mount switching diode
BAV70T High-speed double Diode
BAV756DW Surface Mount Fast Switching Diodes

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
Dual surface mount switching diode FEATURES z For high-speed switching appilication. z Common cathode. Pb Lead-free APPLICATIONS z Small signal switching. Production specification BAV74 ORDERING INFORMATION Type No. Marking BAV74 JA SOT-23 Package Code SOT-23 MAXIMUM RATING @ Ta=25℃ unless otherwise specified Parameter Symbol Limits Diode reverse voltage VR 50 Peak Reverse Voltage VRM 50 Forward Current IF 200 Surge forward current, t=1μs IFS 4.
