MJD42C - Epitaxial Planar PNP Transistor

Key Features

  • z Low formed for surface mount Pb.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
MJD42C PNP Transistor SeCoS
MJD42C Silicon PNP Power Transistor Inchange Semiconductor
MJD42C Complementary Power Transistors Kexin
MJD42C Silicon PNP transistor BLUE ROCKET ELECTRONICS
MJD42C Silicon PNP Transistor MCC

Other Datasheets by Galaxy Microelectronics

Part Number Description
MJD41C Epitaxial Planar NPN Transistor
MJD112 Epitaxial Planar NPN Transistor
MJD117 Epitaxial Planar PNP Transistor
MJD122 Epitaxial Planar NPN Transistor
MJD127 Epitaxial Planar PNP Transistor

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
Epitaxial Planar PNP Transistor FEATURES z Low formed for surface mount Pb application. Lead-free z Electrically similar to popular and TIP42C. z Straight Lead. APPLICATIONS z General purpose amplifier. z Low speed switching applications. Production specification MJD42C TO-251 TO-252 MAXIMUM RATING operating temperature range applies unless otherwise specified Symbol Parameter Value Units VCBO Collector-Base Volage -100 V VCEO Collector-Emitter Voltage -100 V VEBO Emitter-Base Voltage -5 V IC Collector Current -Continuous ICP Collector Current -Peak IB Base Current -6 A -10 A -2 A PC Collector Power Dissipation 1.5 W RθJC Thermal Resistance,Junciton to Case 6.25 ℃/W RθJA Thermal Resistance,Junciton to Ambient 71.
