Datasheet Summary
100mA TinyPowerTM LDO
HT75xx-1
Revision: V2.80 Date: April 10, 2024
HT75xx-1 100mA TinyPowerTM LDO
Features
- Low power consumption
- Low voltage drop
- Low temperature coefficient
- High input voltage (up to 30V)
- Quiescent current 2.5μA
- High output current : 100mA
- Output voltage accuracy: tolerance ±3%
- 3-pin SOT89 and 5-pin SOT23 packages
Applications
- Battery-powered equipment
- munication equipment
- Audio/Video equipment
General Description
The HT75xx-1 series is a set of three-terminal low power high voltage implemented in CMOS technology. They can deliver 100mA output current and allow an input voltage as high as 30V. They are available with several fixed output...
