RT1P440M Overview
RT1P440X is a one chip transistor with built-in bias resistor,NPN type is RT1N440X.
RT1P440M Details
| Part number | RT1P440M |
|---|---|
| Datasheet | RT1P440M RT1P440C Datasheet (PDF) |
| File Size | 477.69 KB |
| Manufacturer | Isahaya Electronics Corporation |
| Description | Silicon PNP Epitaxial Type Transistor |
|
|
