RT1P441M
DESCRIPTION
RT1P441X is a one chip transistor with built-in bias resistor, NPN type is RT1N441X.
FEATURE
- Built-in bias resistor (R1=47kΩ,R2=47kΩ).
APPLICATION
Inverted circuit, switching circuit, interface circuit, driver circuit.
Equivalent circuit
R1 B (IN)
R2
C (OUT)
E (GND)
RT1P441U
1.5 0.35 0.8 0.35
①
②
③
2.0 1.3 0.65 0.65
2.1 0.425 1.25 0.425
①
②
③
1.7 1.0 0.5 0.5
0.22 0.32
0.9 0.7 0～0.1
0.7 0.55 0～0.1 0.12
JEITA：SC-75A JEDEC：－
Terminal Connector ①：Base ②：Emitter ③：Collector
JEITA：SC-70 JEDEC：－
Terminal Connector ①：Base ②：Emitter ③：Collector
0.15 2.5
2.8 1.90 0.95 0.95
〈Transistor〉
Transistor With Resistor For Switching Application Silicon PNP Epitaxial Type
OUTLINE DRAWING UNIT：mm
RT1P441C 2.8
0.65 1.5...
