1SS400
Features
- Fast Switching Speed
- High reliability
Switching Diodes 1SS400
SOD-523
1.2 +0.1 -0.1
+
- +0.05 0.8 -0.05
1.6 +0.1 -0.1
+0.05 0.3 -0.05
Diodes
0.6 +0.1 -0.1
0.77max
+0.05 0.1 -0.02
0.07max
Unit: mm
- Absolute Maximum Ratings Ta = 25℃
Parameter Reverse voltage (Repetitive) Reverse voltage (DC) Average rectified forward current Forward voltage (Repetitive Peak) Surge Current(t=1s) Junction Temperature Storage Temperature range
Symbol
Rating
Unit
225 m A
Isurge
℃
Tstg
-55 to 125
- Electrical Characteristics Ta = 25℃
Parameter Reverse breakdown voltage Forward voltage Reverse voltage leakage current Junction capacitance Reverse recovery time
Symbol
Test Conditions
VR IR= 100 u A
VF IF= 100 m A
VR= 80 V
Cj VR= 0.5 V, f= 1 MHz...
