1SV267
Features
Series connection of 2 elements in a very smallsized package facilitates high-density mounting and permits 1SV267 applied equipment to be made smaller. Small interterminal capacitance (C=0.23p F typ). Small forward series resistance (rs=2.5 typ).
+0.1 2.4 -0.1
SOT-23
2.9+0.1 -0.1
0.4+0.1 -0.1
0.95+0.1 -0.1 1.9+0.1 -0.1
+0.1 1.3 -0.1
Unit: mm 0.1+0.05
-0.01
+0.1 0.97 -0.1
Absolute Maxim um Ratings Ta = 25
Param eter Reverse Voltage Forward Current Allowable Power Dissipation Junction Tem perature Storage tem perature
Sym bol VR IF P Tj T stg
V a lu e 50 50 150 125
-55 to +125
Unit V m A m W
Electrical Characteristics Ta = 25
P aram eter Reverse Voltage Reverse Current Forward Voltage Interterminal Capacitance
Series Resistance
Symbol
Conditions
Min
IR = 10 A
VR = 50 V
IF = 50 m A
VR = 50 V, f = 1 MHz
IF = 5 m A,f = 100 MHz rs
IF = 10 m A,f = 100 MHz
Typ
0.91 0.23 4.0...
