Micro Commercial Components 2SC3265
NPN General Purpose Amplifier
| Part No. | 2SC3265 |
|---|---|
| Datasheet | 2SC3265 Download |
| Manufacturer |  Micro Commercial Components |
| Description | NPN General Purpose Amplifier |
| Buy | Stock & Price |
FEATURES
● Power Switching Application● Complementary to 2SA1298
● Low Frequency Power Amplifier Application
● Halogen Free. “Green” Device (Note 1)
● Moisture Sensitivity Level 1
● Epoxy Meets UL 94 V-0 Flammability Rating
● Lead Free Finish/RoHS Compliant ("P" Suffix Designates RoHS Compliant. See Ordering Information)
MAXIMUM RATINGS
@ 25°C Unless Otherwise Specified● Operating Junction Temperature Range: -55℃ to +150℃
● Storage Temperature Range: -55℃ to +150℃
● Thermal Resistance: 625℃/W Junction to Ambient Parameter Collector-Base Voltage Collector-Emitter Voltage Emitter-Base Voltage Continuous Collector Current Power Dissipation Symbol VCBO VCEO VEBO IC PD Rating 35 30 5 800 200 Unit V V V mA mW Note: 1. Halogen free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and <1000ppm antimony compounds. Internal Structure 3 1 2 1.BASE 2.EMITTER 3.COLLECTOR NPN General Purpose Amplifier SOT-23 A D 3 1 2 CB F E G K H J DIMENSIONS DIM INCHES MIN MAX MM MIN MAX A 0.110 0.120 2.80 3.04 B 0.083 0.104 2.10 2.64 C 0.047 0.055 1.20 1.40 D 0.034 0.041 0.85 1.05 E 0.067 0.083 1.
