Micro Commercial Components RB551V-40
40V 500mA Schottky Barrier Diode
| Part No. | RB551V-40 |
|---|---|
| Datasheet | RB551V-40 Download |
| Manufacturer |  Micro Commercial Components |
| Description | 40V 500mA Schottky Barrier Diode |
| Buy | Stock & Price |
FEATURES
● Halogen free available upon request by adding suffix "-HF"● Marking: D4
● High Current Rectifier Schottky Diode
● Low Voltage, Low Inductance
● For Power Supply
● Epoxy meets UL 94 V-0 flammability rating
● Moisture Sensitivity Level 1
● Lead Free Finish/RoHS Compliant("P" Suffix designates RoHS Compliant. See ordering information)
MAXIMUM RATINGS
Symbol VRM IO IFSM Pd RthJA TJ TSTG Rating Peak Reverse Voltage Continuous Forward Current Non-repetitive Forward Peak Surge Current Power Dissipation Thermal Resistance Junction To Ambient Junction Temperature Storage Temperature Rating 40 500 2 200 500 125 -55 to +150 Unit V mA A mW oC/W к к 500 mA Schottky Barrier Diode 40 Volts SOD-323 A B C E H DELECTRICAL CHARACTERISTICS
@ 25OC Unless Otherwise Specified Symbol Parameter OFF CHARACTERISTICS Min Typ Max Units Forward Voltage VF (IF=500mAdc) --- --- 0.47 Vdc V(BR) Reverse Voltage (IR=0.1mAdc) 40 --- --- Vdc IR Reverse Current (VR=40Vdc) --- --- 100 µAdc G J DIMENSIONS DIM INC...
