MXP4002AF Overview
40V N-ch Power MOSFET General.
MXP4002AF Key Features
- Proprietary New Trench Technology
- RDS(ON),typ.=1.7mΩ@VGS=10V
- Low Gate Charge Minimize Switching Loss
- Fast Recovery Body Diode
MXP4002AF Datasheet Details
| Part number | MXP4002AF |
|---|---|
| Datasheet | MXP4002AF-MaxPowerSemiconductor.pdf |
| File Size | 1.35 MB |
| Manufacturer | MaxPower Semiconductor |
| Description | 40V N-ch Power MOSFET |
|
|
