NST112A Overview
Key Features
- High Accuracy Over –40°C to 125°C 25°C to 45°C: ±0.2°C (Max) -40°C to 125°C: ±1°C (Max)
- High Resolution: 0.015625 °C
- Wide Supply Voltage: 1.5V to 3.6V
- Low Supply Sensitivity: 20m°C/V
- Shutdown current: 0.25 μA (Typ)
- Operating current: 5.7 μA(Typ) at 4Hz conversion cycle
- Supports Temperature Alert
- Supports up to 4 Device Addresses
- Digital Interface: SMBus, I2C
- 4-Ball WCSP (DSBGA) Package Part Number NST112A-CWLR NST112B-CWLR NST112C-CWLR NST112D-CWLR Package DSBGA (4) DSBGA (4) DSBGA (4) DSBGA (4)
