PESD5V0V1BL - Very low capacitance bidirectional ESD protection diodes

General Description

Very low capacitance bidirectional ElectroStatic Discharge (ESD) protection diodes in small Surface-Mounted Device (SMD) plastic packages designed to protect one signal line from the damage caused by ESD and other transients.

Table 1.

Key Features

  • I I I I I Bidirectional ESD protection of one line Very low diode capacitance: Cd = 11 pF Max. peak pulse power: PPP = 45 W Low clamping voltage: VCL = 12.5 V Ultra low leakage current: IRM < 1 nA I I I I ESD protection up to 30 kV IEC 61000-4-2; level 4 (ESD) IEC 61000-4-5 (surge); IPP = 4.8 A AEC-Q101 qualified 1.3.
