PESD5V0V1BA - Very low capacitance bidirectional ESD protection diodes

Download the PESD5V0V1BA datasheet PDF. This datasheet also covers the PESD5V0V1BL variant, as both devices belong to the same very low capacitance bidirectional esd protection diodes family and are provided as variant models within a single manufacturer datasheet.

General Description

Very low capacitance bidirectional ElectroStatic Discharge (ESD) protection diodes in small Surface-Mounted Device (SMD) plastic packages designed to protect one signal line from the damage caused by ESD and other transients.

Table 1.

Key Features

  • I I I I I Bidirectional ESD protection of one line Very low diode capacitance: Cd = 11 pF Max. peak pulse power: PPP = 45 W Low clamping voltage: VCL = 12.5 V Ultra low leakage current: IRM < 1 nA I I I I ESD protection up to 30 kV IEC 61000-4-2; level 4 (ESD) IEC 61000-4-5 (surge); IPP = 4.8 A AEC-Q101 qualified 1.3.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (PESD5V0V1BL_NXPSemiconductors.pdf) that lists specifications for multiple related part numbers.

📁 Similar Datasheet

Part Number Description Manufacturer
PESD5V0V1BA Very low capacitance bidirectional ESD protection diode nexperia
PESD5V0V1BB Very low capacitance bidirectional ESD protection diode nexperia
PESD5V0V1BCSF Ultra low profile bidirectional very low capacitance ESD protection diode NXP
PESD5V0V1BCSF Ultra low profile bidirectional very low capacitance ESD protection diode nexperia
PESD5V0V1BDSF Very low capacitance bidirectional ESD protection diode NXP

Other Datasheets by NXP Semiconductors

Part Number Description
PESD5V0V1BB Very low capacitance bidirectional ESD protection diodes
PESD5V0V1BL Very low capacitance bidirectional ESD protection diodes
PESD5V0V1BSF Ultra low profile bidirectional very low capacitance ESD protection diode
PESD5V0V4UF Very low capacitance unidirectional quadruple ESD protection diode arrays
PESD5V0V4UG Very low capacitance unidirectional quadruple ESD protection diode arrays

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
www.DataSheet4U.com PESD5V0V1BA; PESD5V0V1BB; PESD5V0V1BL Very low capacitance bidirectional ESD protection diodes Rev. 01 — 28 July 2009 Product data sheet 1. Product profile 1.1 General description Very low capacitance bidirectional ElectroStatic Discharge (ESD) protection diodes in small Surface-Mounted Device (SMD) plastic packages designed to protect one signal line from the damage caused by ESD and other transients. Table 1. Product overview Package NXP PESD5V0V1BA PESD5V0V1BB PESD5V0V1BL SOD323 SOD523 SOD882 JEITA SC-76 SC-79 very small ultra small and flat lead leadless ultra small Package configuration Type number 1.2 Features I I I I I Bidirectional ESD protection of one line Very low diode capacitance: Cd = 11 pF Max. peak pulse power: PPP = 45 W Low clamping voltage: VCL = 12.
