MMBD1201 / MMBD1202 / MMBD1203 / MMBD1204 / MMBD1205 — Small Signal Diodes
MMBD1201 / MMBD1202 / MMBD1203 / MMBD1204 / MMBD1205 Small Signal Diodes
Connection Diagram
1201 3
3 1202
3
1 2NC
1NC 2
1203 3
3 1204
2
1
SOT-23
12
12
1205 3
12
Ordering Information
Part Number MMBD1201 MMBD1202 MMBD1203 MMBD1204 MMBD1205
Top Mark 24 25 26 27 28
Package SOT-23 3L SOT-23 3L SOT-23 3L SOT-23 3L SOT-23 3L
Packing Method Tape and Reel Tape and Reel Tape and Reel Tape and Reel Tape and Reel
Absolute Maximum Ratings(1), (2)
Stresses exceeding the absolute maximum ratings may damage the device. The device may not function or be operable above the recommended operating conditions and stressing the parts to these levels is not recommended.
MMBD1201 Datasheet
