MMBT4403L, SMMBT4403L
Switching Transistor
PNP Silicon
Features
• S Prefix for Automotive and Other Applications Requiring Unique
Site and Control Change Requirements; AEC−Q101 Qualified and PPAP Capable
• These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS
Compliant
MAXIMUM RATINGS
Rating Collector −Emitter Voltage Collector −Base Voltage Emitter −Base Voltage Collector Current − Continuous Collector Current − Peak THERMAL CHARACTERISTICS
Symbol VCEO VCBO VEBO
IC ICM
Value −40 −40 −5.0 −600 −900
Unit Vdc Vdc Vdc mAdc mAdc
Characteristic
Total Device Dissipation FR− 5 Board (Note 1) @TA = 25°C Derate above 25°C
Symbol
Max
Unit
PD 225 mW
1.
