BAL99W Datasheet | PanJit Semiconductor

FEATURES - Fast switching speed. - Surface mount package Ideally Suited for Automatic insertion - Electrically Identical to Standard JEDEC - High Conductance - Lead free in pliance with EU Ro HS 2.0 - Green molding pound as per IEC 61249 standard MECHANICAL DATA - Case: SOT-323, Plastic - Terminals: Solderable per MIL-STD-750, Method 2026 - Approx. Weight: 0.0002 ounces, 0.005 grams MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS (TA=25o C unless otherwise noted) Marking Code PARAMETER S YMB OL B AW5 6 W B AV 7 0 W B AV 9 9 W B A L 9 9 W UNITS Reverse Voltage Peak Reverse Voltage V RM Rectifi ed Current (Average), Half Wave Rectifi cation with Resistive Load and f >=50 Hz Peak Forward Surge Current,0.001ms IF S M 150 m A Power Dissi pati on Derate Above 25OC Maximum Forward Voltage Maxi mum DC Reverse Current at 25V 75V Maxi mum Juncti on Capacitance( Notes 1) P TOT 200 m W 0.71 5 @ IF=0.001 A 0 .8 5 5 @ IF =0 .0 1 A 1.0 @...
